RATTMMOTOR Top 20 Products from Power Tools & Hand Tools Brand

RATTMMOTOR ZBX80 100mm Stroke CNC Linear Stage Motion Actuator X Y Z Axis Linear Slide Rail Aluminum Alloy Cross Sliding Table Linear Rail Guide SFU1605 Ballscrew+Nema23 57 Stepper Motor for CNC

Linear Motion Guides

[ZBX80-100mm load capacity] Material: Aluminum Alloy; Effective Stroke: 100mm/3.94 inch; Horizontally loadable: 80KG / 176.37 lb; Vertical carrying: 20KG / 44.09 Ib; Width: 80mm/3.15 inch.

[ZBX80 Size] Total length of the linear Motion Actuator including the stepper motor : 330mm/12.99 inch; Total length of the base plate without motor and bracket: 219mm/8.62 inch.

[High precision ballscrew screw] Bearing steel material, under the premise of guarantting the accuracy of the screw surface chrome-plated to increase the hardness of the screw and improve the load-bearing performance of the slide.

[Nema23 hybrid stepper motor] Motor size: 57 * 57mm * 56mm, Torque: 1.2N.m; Step angle: 1.8°; Current: 3A; Phase inductance: 3.8mH; Phase resistance: 1.1Ω; Shaft: single out shaft; Voltage: 12-36V (typical value 24V); Control mode: pulse control.

[Stepper motor bracket] Add the motor support seat, ensures the coaxiality of the fixed end and prolongs the service life of the motor, screw and coupling;Three-sided closed design effectively reduces dust and dirt from entering the interior of slide, reducing the frequency cleaning, prolonging its life.

[Coupling] Grade 9 high-strength bolts, good locking force, not easy to slip at the cut joints. R-type rounded corners to avoid concentrated stress at the joints; The tolerance of inner diameter is controlled within H7 precision, high concentricity, no gap transmission efficiency by 40%.

Read more Read less

RATTMMOTOR Upgrade 3018-PRO CNC Wood Router Machine Kit 3 Axis GRBL DIY Mini CNC Engraver Milling Machine+Emergency Stop and Limit Switch for Cutting Plastic Acrylic PVC PCB Wood

Milling Machines

Buy on Amazon Find on eBay

[Update CNC machine] The two sides of the Y-axis of the engraving machine are replaced with orange bakelite resin boards, which makes the engraving machine look brighter and more novel. The fixed external frame is made of resin, the work stable is made of aluminum alloy, and the screw rod is made of stainless steel, all of those makes the machine lightweight but more durable, more good apperance.

[Detailed installation and operating instructions] With the English instruction manual from the engraving machine installation to engraving, there are detailed instructions for the X-axis-Y-axis-Z-axis to the overall assembly of the engraving machine, and each installation step parts which is needed has been remarked; With detailed assembly and use videos, even novices don't have to worry about the assembly and use of the machine.

[Added new function] Added an emergency stop button, during the engraving process, if the user encounters an emergency and needs to stop the engraving immediately, user can press the button to stop the operation. Added X/Y/Z axis limit switch, when the engraving machine moves up and down or left and right, it will stop immediately if it exceeds the forming range.

[GRBL Control Board] The GRBL board supports emergency stop and X/Y/Z axis limit functions, which can be used together with the emergency stop button and limit switch on the engraving machine to ensure a safe and simple working environment. Other functions and features: maximum support for 20000RPM spindle, tool setting(probe) , a power switch button and a silent fan cooling. And equipped with a CNC GRBL offline controller.

[Supported engraving materials] Wood, plastic, acrylic, pvc, pcb, carbon fiber, density board, plastic phone cases, rubber stamps, copper , aluminum and other soft materials. It should be noted that materials such as jewelry, jade, stainless steel, stone, ceramics and other similar materials are not supported.

Read more Read less

RATTMMOTOR ZBX150-400mm/15.75" Stroke CNC Linear Stage Motion Actuator X/Y/Z Axis Cross Sliding Table Double Linear Slide Rail Guide 1605 Ballscrew with Limit Switch+Motor Mount Bracket for CNC Router

Linear Motion Actuators

Buy on Amazon Find on eBay

Package Include: 1× 400mm Travel X/Y/Z Axis Cross Sliding Table Linear Slide Rail Guide + 2×Limit Switches + 1×Motor Mount Bracket (without motor).

Effective Stroke: 400mm; Horizontally loadable: 120kg; Vertical carrying: 50kg; Width: 150mm.

Scew: SFU 1605 ballscrew, diamater is 16mm,auucracy is up to 0.03mm.

Guide rail: 20mm square linear rail, hight-speed silent, running smoothly.

Using high-quality aluminum alloy material, beautiful, rust-roof, wear resistant and durable. The latest batch of motor mounts on the shelves have been updated, and the one you receive may also be the latest batch of heavy duty linear stage.

RATTMMOTOR CNC Spindle Motor Kit 2.2KW 220V Water Cooled Spindle Motor Φ80mm ER20 400Hz 24000RPM+2.2KW VFD Drive Inverter 3HP+80mm Spindle Motor Mount Clamp+ER20 Collet+Water Pump for CNC Router

Buy on Amazon Find on eBay

[2.2KW Spindle Motor] : This is a 220V-2.2KW water-cooled 8A Φ 80x213mm spindle motor come with a ER20 nut and collet, and equipped with a 80mm spindle mount. Frequency is 400HZ, 0.003--0.005 accuracy and runout off is Less than 0.01mm. Speed of The Spindle Motor : 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lower than 9000 rpm during the use of the spindle. It should be noted that the spindle motor only can rotate clockwise but not counterclockwise.

[2.2KW VFD Parameters] Control Model: SPWN. Power: 2.2KW. Input：1 or 3 phase 220V 0-50Hz/60Hz. Output：3 phase 220V 0-400Hz. Under normal circumstances, the parameters of the inverter have been set and can be directly connected for use. (Or please follow the instructions to set the parameters).

[80mm Spindle Motor Mount] Material is aluminum,surface sandblasted. Compared with the aluminium profile fixture,the accuracy is much eavier, much higher, and it is hard to deform. Fit for CNC 80mm diameter spindle motor.

[80W 220V Water Pump] Power:80W, Flow: 3500L/H, Hmax: 3.5M, Voltage: 220V. Also suitable for 0.8KW, 1.5KW, 2.2KW, 3KW and other high speed CNC water cooled spindle motor. Please remind that the submersible pump should be completely immersed in water when it is working to ensure that the submersible pump has a certain degree of cooling.

[How to Connect Spindle Motor and VFD] The spindle motor's aviation plug marked with number 1, 2, 3, 4. Number 1, 2, 3 port are connected separately with inverter's port U, V, W. Number 4 is the ground wire, no wiring is required.

Read more Read less

RATTMMOTOR STL-63 110V Pneumatic Punch Press Machine Small Desktop Punching Press Hand Machine 0.5-0.8Mpa Operation Pressure 200KG

Hole Punches

Buy on Amazon Find on eBay

[Model Description:] Model: STL63; Cylinder Diameter: 63mm; Cylinder Stroke: 75mm; Cylinder Stroke Adjustable Range: 50mm: If the maximum cylinder stroke is 75mm, reduce by 50mm, the minimum stroke is 25mm. shortening the stroke can reduce the consumption of air supply.

[Model 63 Parameters] Worktable area: 135*150mm; Closed height: 200mm; Mould shank hole: diameter 16mm; Weight: 16KG; Cylinder specification: 63x75-50; Inlet pipe specification: 8*5MM; Theoretical pressure: gas control/electric control.

[Use industry] Can be equipped with more than 70L air pump, suitable for small accessories, plastic parts, plaster moulding, copper rivets, press-fit and so on.

[Foot switch with high sensitivity] Adopting humanised foot pedal arc design, the foot pedal is more anti-slip. Foot switch to start the work, the foot pedal presses the cylinder down, release the cylinder back, suitable for small processing.

[Product features] Compressed air as power source, high efficiency and easy to operate, can reduce labour, can be applied to manual operation, automated assembly line integration operation; according to different products or moulds, adjust the height, speed, stroke, pressure size and stamping time.

Read more Read less

RATTMMOTOR CNC Spindle Motor Kit 110V 2.2KW Water Cooled 80mm Spindle Motor ER20 24000RPM 400HZ+2.2KW VFD 110V Single to 3 Phase Inverter Variable Frequency Drive+Mount Clamp+Water Pump+ER20 Collet

Milling Machines

Buy on Amazon Find on eBay

[Package Include] : 1 x 2.2KW Water Cooled Spindle Motor 1 x 2.2KW VFD 1 x 80mm Spindle Motor Mount(with 3pcs screws) 1 x 80W Water Pump 1 x 5m Pipe 1 x ER20 Wrench 14 x ER20 Collet（1mm, 2mm, 3mm, 3.175mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm）

[2.2KW Spindle Motor] : This is a 110V-2.2KW water-cooled 15A Φ 80x213mm spindle motor come with a ER20 nut and collet. Frequency is 400HZ, 0.003--0.005 accuracy and runout off is Less than 0.02mm. Speed of The Spindle Motor : 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lower than 9000 rpm during the use of the spindle. It should be noted that the spindle only can rotate clockwise but not counterclockwise.

[2.2KW VFD] Parameters: Input Voltage: 110V(+/-15%), Output Voltage: 110VAC, Input Frequency: 50-60 Hz, Output Frequency: 0-1000 Hz, Input Phase: 1 phase, Output Phase: 3 phase. It provide a variety of fault protection functions: over-current, over-voltage, under-voltage, over-heat, overload, lack of equal real-time monitoring and protection to ensure safe operation.

Other Fuctions: With over torque and under torque detection; With jump frequency control function, it can effectively suppress mechanical resonance and make the system more stable and reliable.It can also avoid the impact of production due to instantaneous power failure because of instantaneous power-down retention function. What's more, it supports multiple frequency settings: digital setting, analog setting, PID setting, RS485 communication setting,ect.

[How to Connect Spindle Motor and VFD] The spindle motor's aviation plug marked with number 1, 2, 3, 4. Number 1, 2, 3 port are connected with inverter's port U, V, W respectively. Number 4 is the ground wire, no wiring is required.

Read more Read less

RATTMMOTOR No powered Multi-function Lathe chuck spindle assemblies 895 Motor Rotary Lathe Woodworking Spindle Motor Chuck 63mm for CNC Lathe Grinder machine Table Saw (4 Jaw 63mm)

Buy on Amazon Find on eBay

[6000-12000RPM] No-load current 1.5A, turning force: 8KG/cm, torque: 0.78N.m, rated voltage 12-24V DC, motor speed up to 12000rpm, 12V/6000rpm, 24V/12000rpm, , supports forward and reverse, high speed, strong momentum.

[K02-63mm Self-centering Chuck] Jaw: 4 Jaw; Internal jaw clamping: 1-50mm; External jaw clamping: 16-50mm; Connection form: threaded connection, threaded port size: M14.

[XL10 teeth 5mm + XL30 teeth 15mm motor synchronous wheel] Aluminium alloy synchronous wheel, high transmission efficiency, and smooth transmission, with buffer, vibration damping capacity, low noise. Synchronous wheel reduction ratio 1:3.

[110XL belt] Circumference 279.44mm, number of teeth 55, transmission speed ratio range, compact structure suitable for multi-axis transmission, without lubrication; belt selection of high quality materials, anti-wear.

[Chuck Assembly Parts Overview] 1*Chuck; 2*Chuck spanner; 1*Through-hole spindle rod; 1*Spindle bearing housing; 1*XL10 tooth 5mm synchro wheel; 1*XL30 tooth synchro wheel; 1*XL110 belt; 3*Inner 6-angle spanner.

Read more Read less

RATTMMOTOR CNC Controller Kit, 4 Axis CNC Kit with Nema23 Stepper Motor 57*76mm 270Oz-in 3A 1.8Nm, TB6600 Driver 4A, USB Mach3 CNC Motion Control Card Breakout Board, 24V Power Supply for CNC Machine

Electrical Motor Controls

Buy on Amazon Find on eBay

[Motor and TB6600 Driver wiring] Stepper motor's RED wire connects to driver's A+ port. Stepper motor's GREEN wire connects to driver's A- port. Stepper motor's YELLOW wire connects to driver's B+ port. Stepper motor's BLUE wire connects to driver's B- port.

[Control Card and TB6600 Driver wiring (X-axis as an example) ] Driver's "Pul+" connects to control card's XP+ pin , Driver's "DIR+" connects to control card's XD+ pin , Driver's " PUL- " pin and " DIR- " connection to USB Mach3 control card's " GND ".

[Low Noise/High Torque Hybrid Stepper Motor] 23HS8430 2-phase stepper motor with a shaft diameter of 8mm, a current of 3A and an angle of 1.8°, is made of durable metal on the outside, and the perfect combination of rubber and rotor fills up the inner space and stabilizes the overall structure of the motor. The coils are made of pure copper enameled wire and the torque is up to 270oz-in (180N.cm/18kg-cm). The motor runs quietly and doesn't cause the generator to become too hot over a long time.

[Support Forward and Reverse Control Stepper Motor Driver] 42/57 TB6600 stepper motor driver with input voltage anti-reverse connection and overheat/overcurrent short circuit protection, equipped with red warning light. through the 3-digit DIP switch, you can choose 7 subdivisions (1, 2 / A, 2 / B, 4, 8, 16, 32) and 8 subdivisions (0.5A, 1.0A 1.5A, 2.0A, 2.5A, 3.0A, 3.5A) current control.

[USB Interface, Drive-free Design 4-Axis Linkage Control Card] Output pulse frequency of 400KHz, using the minimum error interpolation algorithm, high processing accuracy. Supports up to 4 axes of linkage control, of which the 4th axis can be set as the slave axis. The control card can be connected to PC-compatible computers such as laptops, desktops, tablets and other computers with a USB interface. As long as Mach3 is running, the control card can be used without installing any drivers.

[Multi-function control card] With support for automatic home return, automatic tool setting, emergency stop input, limit switch access, spindle control (PWM mode and Him electrical mode), handwheel interface and other functions. Provide up to 12-way digital signal input, 4-way with optocoupler digital signal input and isolated relay output. Strong anti-interference and high reliability.

[Stable output 24V DC power supply] Over-current, over-voltage and overload protection, power supply stable power supply, electrical energy conversion rate of up to 90%, higher efficiency. Together with the heat dissipation fan design, shell hollow design, heat dissipation ability faster and stronger, more durable performance.

Read more Read less

RATTMMOTOR JN400S Power Feed X-Axis 650 in-lb Torque, 2-200RPM, 110V Milling Table Power Feed for Bridgeport and Some Knee Type Milling Machine

Milling Machines

Buy on Amazon Find on eBay

[Parameter] Model: JN400S handle model; Axis: X Axis; Power: 90W; Voltage: 110V; Weight: 6KG; Current: 2.8AMP; Speed range: 2-200RMP; Torque: 650IN-LB.

[Stable performance, precision and durable bearings] When fast escorting, if the tool collides with the workpiece, or turn left or right instantly, it is equipped with a special safety device to transmit plastic gears and electronic parts without damage. Small use sound, no noise, high speed, effectively improve the working efficiency.

[Simple operation, convenient processing] Good efficiency in speed adjustment, when the tool is cutting, the change of escorting speed is small, then the cutting surface precision is good; when escorting at low speed, the machine will not shake.

[Safe and Stable] The knife walker adopts 110V safety voltage, safe and stable operation, the gear ratio of the transmission plastic gear and the motor core shaft is infinitesimal, the two gears will not return to the origin, the plastic gear has a long service life, and the more you use the gear, the smaller the sound.

[Feature-1] Mainly used for milling machine table in the X-coordinate direction when the work movement, to achieve forward and reverse rotation and infinitely artificial speed regulation, instead of the traditional gear box speed change mechanism.

[Feature-2] Enhanced torque to boost low-speed torque for low-speed heavy-duty cutting capability. 0.2-second extreme brake design allows for quick forward and reverse operation to save machining time.

Read more Read less

RATTMMOTOR 2.2KW Spindle Motor 220V Square Air Cooled ER20, 24000RPM High Speed Spindle 4 Bearings 3-Phase 6A 400Hz for CNC Router Engraver Milling Cutting Machine

Buy on Amazon Find on eBay

[Simple discreption] This is a 220V 2.2KW Square air-cooled spindle motor come with a ER20 nut and collet. Current is 6A, frequency is 400HZ, precision tapered bore is less than 0.005mm and runout off is Less than 0.01mm.

[Spindle speed] The speed of the spindle motor is 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lowered than 9000 rpm during the use of the spindle. Also ,it should be noted that the spindle only can rotate clockwise but not counter-clockwise.

[How to wring it to Inverter] The spindle's terminal U1, V1, W1 are connected separately to inverter's terminal U, V,W. Connect any 2pin terminal "R", "S" or "T" of the inverter to "220VAC".

[Note] Before driving, turn the shaft by hand first. The temperature's rise caused by the high-speed rotation of the spindle motor can be eliminated by the coolant circulation system.

[Main application] Wood, Aluminum, Glass, PVC industry.The Spindle motor is mainly suitable for NON-metallic engraving.

Read more Read less

RATTMMOTOR ATC BT30 Non-Powered Spindle Kit 5000RPM Cylinder Pneumatic Semi-Automatic Tool Changer Spindle Motor with Bracket for Metal Engraving Drilling Milling

Buy on Amazon Find on eBay

[Spindle accuracy/cylinder model ] 5pcs Deep groove ball bearings are used, the shaft is heat treated and fully ground with ultra-high hardness, the taper runout inside the spindle is 0.02~0.05mm. Cylinder model ROANY SDA 80*10, 0.8 pneumatic pressure, the pulling force is 300kg.

[BT30 toolholder] BT30-ER20 toolholder, spigot model BT30-45°, without ER cartridge; mainly used for roughing: drilling, tapping, milling head, milling and other heavy cutting, not suitable for finishing.

[Aluminium alloy] Shell made of 7075 aluminium alloy, spindle with one-piece spindle holder, suitable for home computers, small machines, microcomputers, and to achieve automatic tool change function.

[Maximum speed without power] 5000rpm, this product is a powerless tool changer spindle without motor, so the power is determined according to the motor you equipped.

[Quasi-stop solution] Adopts servo motor as power, the servo motor itself has precise stop function, it can stop at the same angle every time.

Read more Read less

RATTMMOTOR YPMC-1000W 220V Servo Motor Kit with Servo Motor Driver, CNC Controller Kit for CNC Engraver Milling Machine/Robot (Without Brake)

RC Servos

Buy on Amazon Find on eBay

[Motor parameters] Model: A2M-80SV03230; With brake: No; Power: 1000W; Number of poles: 5 pairs; Rated power supply: 220V; Rated speed: 3000r/min; Peak speed: 6000r/min; Rated torque: 3.8 N.m; Max torque: 11.4 N.m; Rated current: 4.8A; Max current: 14.4A; Ender Resolution: 10000ppr; Protection structure: IP65; Impact strength: 98m/s²; Vibration resistance: 49m/s².

[Triple Overload/Powerful Motor] The motors are made of high quality materials with 3 times overload capacity, built-in disturbance torque observer, extremely strong resistance to external disturbances and stable operation. The motor also has features such as: high torque, no lost step, low noise, fast response, small size, high controllability, and has been operated.

[Driver Parameters] Model: S2SVD20; Maximum current: 20A; Input voltage: AC220V (50/60Hz); Cooling method: Heat dissipation air cooling; Encoder type: 17 bit magnetic encoder. ( Note: Controllers with CN ports need to be customized separately: support RS-232, RS-485 interface, modbus communication protocol, can be connected to the PC, PLC and other host computer equipment. )

[Driver Multiple Functions] The driver adopts advanced algorithm, low-speed operation is more stable, at the same time, the high-performance encoder ensures the accuracy of the motor; Reserved multiple IO function interface, arbitrary combination to meet the functional needs of different occasions.

[AC Servo Features] Three types of command pulse input, i.e. command direction and pulse input, clockwise/counterclockwise pulse input, and quadrature pulse input with 90 degree phase difference. Position control, speed control, torque control, and extension control can be converted through Modbus communication to meet common applications. The display mode can be switched between three modes: monitor mode, auxiliary mode, and user parameter mode.

[Application Areas] Suitable for a variety of automation equipment and instruments, such as screw machines, automatic equipment, medical equipment, semiconductor equipment, engraving equipment, measuring equipment, AGV carts, etc.

Read more Read less

RATTMMOTOR 2.2KW Water Cooled Spindle Kit 110V Spindle Motor 24000RPM+2.2KW VFD 110V Inverter 3HP Variable Frequency Drive+80mm Spindle Mount+80W Water Pump+ER20 Collet for CNC Router Milling Machine

Buy on Amazon Find on eBay

[2.2KW Spindle Motor] : This is a 110V-2.2KW water-cooled 15A Φ 80x213mm spindle motor come with a ER20 nut and collet, and equipped with a 80mm spindle mount. Frequency is 400HZ, 0.003--0.005 accuracy and runout off is Less than 0.01mm. Speed of The Spindle Motor : 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lower than 9000 rpm during the use of the spindle. It should be noted that the spindle motor only can rotate clockwise but not counterclockwise.

[2.2KW VFD Parameters] Control Model: SPWN. Power: 2.2KW. Input：1 or 3 phase 110V 0-50Hz/60Hz. Output：3 phase 110V 0-400Hz.Under normal circumstances, the parameters of the inverter have been set and can be directly connected for use. (Or please follow the instructions to set the parameters).

[80mm Spindle Motor Mount] Material is aluminum,surface sandblasted. Compared with the aluminium profile fixture,the accuracy is much eavier, much higher, and it is hard to deform. Fit for CNC 80mm diameter spindle motor.

[80W 110V Water Pump] Power:80W, Flow: 3500L/H, Hmax: 3.5M, Voltage: 110V. Also suitable for 0.8KW, 1.5KW, 2.2KW, 3KW and other high speed CNC water cooled spindle motor. Please remind that the submersible pump should be completely immersed in water when it is working to ensure that the submersible pump has a certain degree of cooling.

[How to Connect Spindle Motor and VFD] The spindle motor's aviation plug marked with number 1, 2, 3, 4. Number 1, 2, 3 port are connected separately with inverter's port U, V, W. Number 4 is the ground wire, no wiring is required.

Read more Read less

RATTMMOTOR No Powered Multi-Function Lathe Chuck Spindle Assemblies Rotary Lathe Woodworking Motor Chuck 100mm for CNC Lathe Grinder Drilling Machine Table Saw (3 Jaw 100mm)

Buy on Amazon Find on eBay

[Basic parameters] Chuck Diameter: 100MM; Motor Wheel: 12 teeth bore 10; Belt Model: 150XL; Bearing I.D.: 25MM; Supporting Speed: 4000 RPM; Spindle Synchronous Wheel: XL45 teeth; Spindle Connector: Shank Diameter: 25MM; Spindle Block Center Height: 42mm; Length, Width, and Height: 200*150*100mm; Weight: 4.9KG.

[Chuck parameters] Chuck type: 3 jaw chuck; chuck diameter: 100mm; positive jaws clamping: 2-30mm; positive jaws support: 30-90mm; reverse jaws clamping: 30-80mm; Limit speed: 3500r/min; Maximum input torque: 60N.m; Maximum static clamping force: 10KN.

[45-tooth and 12-tooth synchronizer wheels] Synchronous wheels are made of aluminum alloy with high transmission efficiency and strong power. The transmission is smooth, with cushioning and vibration damping ability, and low noise. Synchronous wheel speed ratio: 1 : 3.75.

[XL150 Belt] Model: 150XL; Circumference: 381mm; Number of teeth: 75; Center distance between 45 teeth and 12 teeth synchronous wheel: 118mm; Width: 10mm; Thickness: 2.3mm; Pitch: 5.08mm; Tooth height: 1.27mm.

[Chuck assembly kit parts] 1*Chuck spindle assembly; 1*Aluminum alloy bearing housing connecting plate; 4* fixing screws for housing connecting plate; 1*Three-jaw 100mm chuck; 3*Counter-jaw chuck; 1*Chuck wrench; 1*XL12 tooth spindle synchronous wheel; 1*XL45 tooth spindle synchronous wheel; 1 Set wrenches.

Read more Read less

RATTMMOTOR Nema34 12N.m Closed Loop Hybrid Servo Motor Stepper Motor 12nm 1700oz-in 156mm 6A 2 Phase & HSS86 Servo Driver & 3m Wire CNC Controller Kit for CNC Router Engraving Milling Machine

Motor Drives

Buy on Amazon Find on eBay

Specifications of Motor: Model is 86HSE156; Holding Torque:12N.m 1700oz-in; Rated Current:6A; Peak Current:8A; Phase:2-Phase; Size:86x86x156mm; Step Angle:1.8 degree; Motor Lead Wire: 4-Wires; Encoder lines:1000; Shaft diameter: 14mm

Specifications of Driver: Model is 2HSS86; Type:2-Phase Hybrid Stepper Servo Driver; Frequency:0-200KHz; Insulation resistance:>=500MΩ; Voltage: AC 24-70V or DC 30-100V input

Advantages:Stepper motor closed loop system,never lose step; The stepper motor control has a new generation of 32-bit DSP; The vector control technology can ensure the accuracy of the motor; Improve motor output torque and working speed; Automatic current adjustment based on load; Pulses response frequency can reach 200KHZ; 16 kinds microsteps choice,highest 51200 microsteps/rev

More Functions: It supports over-current protection, over-voltage protection, position outside the tolerance protection; The build-in place in position and alarm output signal can help the upper monitor to monitor and control,the function of position ultra difference alarm can ensure the machine work safely

Widely used: Closed loop stepper system can be applied to all kinds small automatic equipment and instrument;Such as engraving machine, special industrial sewing machine, stripping machine, marking machine, cutting machine, graph plotter, cnc machine, automatic assembly equipment and so on;This motor driver kit fits all types of machine load conditions including pulley and low stiffness pulley without adjusting the gain parameters

Read more Read less

RATTMMOTOR 500W CNC Air Cooled Spindle Motor ER11 12000RPM + Input Voltage AC110V-220V Speed Controller with Power Supply + 52mm Clamp for CNC Router Milling Machine

Motor Speed Controllers

Buy on Amazon Find on eBay

Air Cooled Spindle-- Power: 500W; Idling Speed: 2000-12000r/min; Torque：0.5NM; Diameter: 52mm.

Speed Controller-- Armature output voltage: DC0 ~ 100V adjustable; Input Voltage: AC100-AC220V±10% Global voltage 50/60Hz(User can change the power supply to 110V according to their needs); Current Limit: 6A; Wiring: Terminal type (Convenient and fast).

Adopt pulse width technology to make the speed more stable, and the speed is high under low speed.

With overcurrent protection cut-off device to make performance more reliable; With a soft start device to eliminate motor starting current is too large.

Note: This motor has quiet operation, small volume and high speed, and the rear end of the motor is reinforced with a cooling fan, which can be safely worked for a long time!

Read more Read less

RATTMMOTOR EBX1605 400mm / 15.75" CNC Linear Stage Actuator, Double Optical Axis Linear Slide Rail and 1605 Ball Screw CNC Linear Motion Rail Guide with Nema23 Stepper Motor for DIY CNC Router Machine

Linear Motion Guides

Buy on Amazon Find on eBay

[Compact Structure] The base is 2080 profile, the tail end bearing piece, front end is equipped with Nema23 stepper motor and the flange piece connecting the motor, with the load-bearing slide table, the 1605 lead screw and the coupling, adding a stable bearing, and the double optical axis design. Working Length: 400mm/15.75inch.

[Flexible Installation] 80mm aluminum profile base, M4 movable nut at the bottom, side mounting groove for easy fixing, M3 nut can be installed with limit, easy to install. This linear stage can be used in combination with multi-axis, horizontal cross, gantry type, three-axis type, four-axis type, etc.

[Stable Operation] Stable bearings are added at the motor end to better maintain accuracy and improve operation stability. 80*50mm slider, embedded with linear bearing to ensure uniform axial force and ensure running positioning accuracy.

[High Precision] 1605 ball screw, C7 grade screw accuracy, screw reciprocating accuracy of 0.01mm, repeat positioning accuracy of ±0.03mm, accurate positioning, good hardness, quiet operation, and long service life.

[Strong Load Capacity] Two 12mm optical shaft transmission, double shaft support load is larger, the horizontal load is 50KG/110.23Ib, and the vertical load is 10KG/22.05Ib. It is suitable for lathes, CNC machine tools, machining, mechanical equipment, automation devices and other industrial automation fields.

Read more Read less

RATTMMOTOR ZBX150-100mm/3.94" Stroke CNC Linear Stage Motion Actuator X/Y/Z Axis Cross Sliding Table Double Linear Slide Rail Guide 1605 Ballscrew with Limit Switch+Motor Mount Bracket for CNC Router

Linear Motion Actuators

Buy on Amazon Find on eBay

Package Include: 1× 100mm Travel X/Y/Z Axis Cross Sliding Table Linear Slide Rail Guide + 2×Limit Switches + 1×Motor Mount Bracket (without motor).

Effective Stroke: 100mm; Horizontally loadable: 120kg; Vertical carrying: 50kg; Width: 150mm.

Scew: SFU 1605 ballscrew, diamater is 16mm,auucracy is up to 0.03mm.

Guide rail: 20mm square linear rail, hight-speed silent, running smoothly.

Using high-quality aluminum alloy material, beautiful, rust-roof, wear resistant and durable. The latest batch of motor mounts on the shelves have been updated, and the one you receive may also be the latest batch of heavy duty linear stage.

RATTMMOTOR CNC Spindle Motor Water Cooled 2.2KW 220V Spindle Motor ER20 Collet 80mm Diameter 8A 400HZ 24000RPM for CNC Router Engraver Milling Machine

Buy on Amazon Find on eBay

[How to Connect The Spindle Motor] The spindle motor's aviation plug marked with number 1, 2, 3, 4. Number 1, 2, 3 port are connected with inverter's port U, V, W respectively. Number 4 is the ground wire, no wiring is required.

[Simple Introduction] This is a 220V-2.2KW water-cooled 8A Φ 80x213mm spindle motor come with a ER20 nut and collet. Frequency is 400HZ, 0.003--0.005 accuracy and runout off is less than 0.01mm. It is mainly suitable for non-metallic engraving,such as wood carving/engraving machine, advertisement engraving machine,CNC machine.

[Speed of The Spindle Motor] 0-24000RPM. Because it is a high-speed spindle motor, the spindle speed must not be lower than 9000 rpm during the use of the spindle. It should be noted that the spindle only can rotate clockwise but not counterclockwise.

ISO9001 quality certifications which means this item is the top quality item. In extremely high speed working environment, ordinary bearing can not ensure this high rotate speed for using for long time.

[1 Year Warranty] We offer 1 year warranty, if you have any questions about the product, please contact the seller for a satisfactory solution.

[Advantages of The Spindle] The design of the dust-proof cover on the front of the spindle and the use of stainless steel body can effectively prevent dust, water and rust.

Read more Read less

RATTMMOTOR YPMC-750W 110V Servo Motor Kit, Servo Motor with Servo Motor Driver CNC Controller Kit for CNC Engraver Milling Machine/Robot (Without Brake)

Electrical Motor Controls

Buy on Amazon Find on eBay

[Motor parameters] Model: A2M110-80SV02430; With brake: No; Power: 750W; Number of poles: 5 pairs; Rated power supply: 110V; Rated speed: 2500r/min; Peak speed: 3000r/min; Rated torque: 2.4N.m; Max torque: 7.2 N.m; Ender Resolution: 10000ppr; Protection structure: IP65; Impact strength: 98m/s²; Vibration resistance: 49m/s².

[Triple Overload/Powerful Motor] The motors are made of high quality materials with 3 times overload capacity, built-in disturbance torque observer, extremely strong resistance to external disturbances and stable operation. The motor also has features such as: high torque, no lost step, low noise, fast response, small size, high controllability, and has been operated.

[Driver Parameters] Model: S2SVD15-110; Input voltage: AC110V (50/60Hz); Cooling method: Heat dissipation air cooling; Encoder type: 17 bit magnetic encoder. ( Note: Controllers with CN ports need to be customized separately: support RS-232, RS-485 interface, modbus communication protocol, can be connected to the PC, PLC and other host computer equipment. )

[Driver Multiple Functions] The driver adopts advanced algorithm, low-speed operation is more stable, at the same time, the high-performance encoder ensures the accuracy of the motor; Reserved multiple IO function interface, arbitrary combination to meet the functional needs of different occasions.

[AC Servo Features] Three types of command pulse input, i.e. command direction and pulse input, clockwise/counterclockwise pulse input, and quadrature pulse input with 90 degree phase difference. Position control, speed control, torque control, and extension control can be converted through Modbus communication to meet common applications. The display mode can be switched between three modes: monitor mode, auxiliary mode, and user parameter mode.

[Application Areas] Suitable for a variety of automation equipment and instruments, such as screw machines, automatic equipment, medical equipment, semiconductor equipment, engraving equipment, measuring equipment, AGV carts, etc.

Read more Read less

RATTMMOTOR

RATTMMOTOR Best Sellers

RATTMMOTOR ZBX80 100mm Stroke CNC Linear Stage Motion Actuator X Y Z Axis Linear Slide Rail Aluminum Alloy Cross Sliding Table Linear Rail Guide SFU1605 Ballscrew+Nema23 57 Stepper Motor for CNC

RATTMMOTOR Upgrade 3018-PRO CNC Wood Router Machine Kit 3 Axis GRBL DIY Mini CNC Engraver Milling Machine+Emergency Stop and Limit Switch for Cutting Plastic Acrylic PVC PCB Wood

RATTMMOTOR ZBX150-400mm/15.75" Stroke CNC Linear Stage Motion Actuator X/Y/Z Axis Cross Sliding Table Double Linear Slide Rail Guide 1605 Ballscrew with Limit Switch+Motor Mount Bracket for CNC Router

RATTMMOTOR CNC Spindle Motor Kit 2.2KW 220V Water Cooled Spindle Motor Φ80mm ER20 400Hz 24000RPM+2.2KW VFD Drive Inverter 3HP+80mm Spindle Motor Mount Clamp+ER20 Collet+Water Pump for CNC Router

RATTMMOTOR STL-63 110V Pneumatic Punch Press Machine Small Desktop Punching Press Hand Machine 0.5-0.8Mpa Operation Pressure 200KG

RATTMMOTOR CNC Spindle Motor Kit 110V 2.2KW Water Cooled 80mm Spindle Motor ER20 24000RPM 400HZ+2.2KW VFD 110V Single to 3 Phase Inverter Variable Frequency Drive+Mount Clamp+Water Pump+ER20 Collet

RATTMMOTOR No powered Multi-function Lathe chuck spindle assemblies 895 Motor Rotary Lathe Woodworking Spindle Motor Chuck 63mm for CNC Lathe Grinder machine Table Saw (4 Jaw 63mm)

RATTMMOTOR CNC Controller Kit, 4 Axis CNC Kit with Nema23 Stepper Motor 57*76mm 270Oz-in 3A 1.8Nm, TB6600 Driver 4A, USB Mach3 CNC Motion Control Card Breakout Board, 24V Power Supply for CNC Machine

RATTMMOTOR JN400S Power Feed X-Axis 650 in-lb Torque, 2-200RPM, 110V Milling Table Power Feed for Bridgeport and Some Knee Type Milling Machine

RATTMMOTOR 2.2KW Spindle Motor 220V Square Air Cooled ER20, 24000RPM High Speed Spindle 4 Bearings 3-Phase 6A 400Hz for CNC Router Engraver Milling Cutting Machine

RATTMMOTOR ATC BT30 Non-Powered Spindle Kit 5000RPM Cylinder Pneumatic Semi-Automatic Tool Changer Spindle Motor with Bracket for Metal Engraving Drilling Milling

RATTMMOTOR YPMC-1000W 220V Servo Motor Kit with Servo Motor Driver, CNC Controller Kit for CNC Engraver Milling Machine/Robot (Without Brake)

RATTMMOTOR 2.2KW Water Cooled Spindle Kit 110V Spindle Motor 24000RPM+2.2KW VFD 110V Inverter 3HP Variable Frequency Drive+80mm Spindle Mount+80W Water Pump+ER20 Collet for CNC Router Milling Machine

RATTMMOTOR No Powered Multi-Function Lathe Chuck Spindle Assemblies Rotary Lathe Woodworking Motor Chuck 100mm for CNC Lathe Grinder Drilling Machine Table Saw (3 Jaw 100mm)

RATTMMOTOR Nema34 12N.m Closed Loop Hybrid Servo Motor Stepper Motor 12nm 1700oz-in 156mm 6A 2 Phase & HSS86 Servo Driver & 3m Wire CNC Controller Kit for CNC Router Engraving Milling Machine

RATTMMOTOR 500W CNC Air Cooled Spindle Motor ER11 12000RPM + Input Voltage AC110V-220V Speed Controller with Power Supply + 52mm Clamp for CNC Router Milling Machine

RATTMMOTOR EBX1605 400mm / 15.75" CNC Linear Stage Actuator, Double Optical Axis Linear Slide Rail and 1605 Ball Screw CNC Linear Motion Rail Guide with Nema23 Stepper Motor for DIY CNC Router Machine

RATTMMOTOR ZBX150-100mm/3.94" Stroke CNC Linear Stage Motion Actuator X/Y/Z Axis Cross Sliding Table Double Linear Slide Rail Guide 1605 Ballscrew with Limit Switch+Motor Mount Bracket for CNC Router

RATTMMOTOR CNC Spindle Motor Water Cooled 2.2KW 220V Spindle Motor ER20 Collet 80mm Diameter 8A 400HZ 24000RPM for CNC Router Engraver Milling Machine

RATTMMOTOR YPMC-750W 110V Servo Motor Kit, Servo Motor with Servo Motor Driver CNC Controller Kit for CNC Engraver Milling Machine/Robot (Without Brake)

RATTMMOTOR FAQs

RATTMMOTOR

RATTMMOTOR Best Sellers

RATTMMOTOR ZBX80 100mm Stroke CNC Linear Stage Motion Actuator X Y Z Axis Linear Slide Rail Aluminum Alloy Cross Sliding Table Linear Rail Guide SFU1605 Ballscrew+Nema23 57 Stepper Motor for CNC

RATTMMOTOR Upgrade 3018-PRO CNC Wood Router Machine Kit 3 Axis GRBL DIY Mini CNC Engraver Milling Machine+Emergency Stop and Limit Switch for Cutting Plastic Acrylic PVC PCB Wood

RATTMMOTOR ZBX150-400mm/15.75" Stroke CNC Linear Stage Motion Actuator X/Y/Z Axis Cross Sliding Table Double Linear Slide Rail Guide 1605 Ballscrew with Limit Switch+Motor Mount Bracket for CNC Router

RATTMMOTOR CNC Spindle Motor Kit 2.2KW 220V Water Cooled Spindle Motor Φ80mm ER20 400Hz 24000RPM+2.2KW VFD Drive Inverter 3HP+80mm Spindle Motor Mount Clamp+ER20 Collet+Water Pump for CNC Router

RATTMMOTOR STL-63 110V Pneumatic Punch Press Machine Small Desktop Punching Press Hand Machine 0.5-0.8Mpa Operation Pressure 200KG

RATTMMOTOR CNC Spindle Motor Kit 110V 2.2KW Water Cooled 80mm Spindle Motor ER20 24000RPM 400HZ+2.2KW VFD 110V Single to 3 Phase Inverter Variable Frequency Drive+Mount Clamp+Water Pump+ER20 Collet

RATTMMOTOR No powered Multi-function Lathe chuck spindle assemblies 895 Motor Rotary Lathe Woodworking Spindle Motor Chuck 63mm for CNC Lathe Grinder machine Table Saw (4 Jaw 63mm)

RATTMMOTOR CNC Controller Kit, 4 Axis CNC Kit with Nema23 Stepper Motor 57*76mm 270Oz-in 3A 1.8Nm, TB6600 Driver 4A, USB Mach3 CNC Motion Control Card Breakout Board, 24V Power Supply for CNC Machine

RATTMMOTOR JN400S Power Feed X-Axis 650 in-lb Torque, 2-200RPM, 110V Milling Table Power Feed for Bridgeport and Some Knee Type Milling Machine

RATTMMOTOR 2.2KW Spindle Motor 220V Square Air Cooled ER20, 24000RPM High Speed Spindle 4 Bearings 3-Phase 6A 400Hz for CNC Router Engraver Milling Cutting Machine

RATTMMOTOR ATC BT30 Non-Powered Spindle Kit 5000RPM Cylinder Pneumatic Semi-Automatic Tool Changer Spindle Motor with Bracket for Metal Engraving Drilling Milling

RATTMMOTOR YPMC-1000W 220V Servo Motor Kit with Servo Motor Driver, CNC Controller Kit for CNC Engraver Milling Machine/Robot (Without Brake)

RATTMMOTOR 2.2KW Water Cooled Spindle Kit 110V Spindle Motor 24000RPM+2.2KW VFD 110V Inverter 3HP Variable Frequency Drive+80mm Spindle Mount+80W Water Pump+ER20 Collet for CNC Router Milling Machine

RATTMMOTOR No Powered Multi-Function Lathe Chuck Spindle Assemblies Rotary Lathe Woodworking Motor Chuck 100mm for CNC Lathe Grinder Drilling Machine Table Saw (3 Jaw 100mm)

RATTMMOTOR Nema34 12N.m Closed Loop Hybrid Servo Motor Stepper Motor 12nm 1700oz-in 156mm 6A 2 Phase & HSS86 Servo Driver & 3m Wire CNC Controller Kit for CNC Router Engraving Milling Machine

RATTMMOTOR 500W CNC Air Cooled Spindle Motor ER11 12000RPM + Input Voltage AC110V-220V Speed Controller with Power Supply + 52mm Clamp for CNC Router Milling Machine

RATTMMOTOR EBX1605 400mm / 15.75" CNC Linear Stage Actuator, Double Optical Axis Linear Slide Rail and 1605 Ball Screw CNC Linear Motion Rail Guide with Nema23 Stepper Motor for DIY CNC Router Machine

RATTMMOTOR ZBX150-100mm/3.94" Stroke CNC Linear Stage Motion Actuator X/Y/Z Axis Cross Sliding Table Double Linear Slide Rail Guide 1605 Ballscrew with Limit Switch+Motor Mount Bracket for CNC Router

RATTMMOTOR CNC Spindle Motor Water Cooled 2.2KW 220V Spindle Motor ER20 Collet 80mm Diameter 8A 400HZ 24000RPM for CNC Router Engraver Milling Machine

RATTMMOTOR YPMC-750W 110V Servo Motor Kit, Servo Motor with Servo Motor Driver CNC Controller Kit for CNC Engraver Milling Machine/Robot (Without Brake)

RATTMMOTOR FAQs

Similar Brands
