Juried Engineering CD14538BE CD14538B CD14538 CMOS Dual Precision Monostable Multivibrator Breadboard-Friendly IC DIP-16 (1 Piece)
Features
- Retriggerable/resettable Capability, Trigger And Reset Propagation Delays Independent Of RX, CX, Triggering From Leading Or Trailing Edge, Maximum Input Current Of 1 µA At 18 V Over Full Package-Temperature Range; 100 nA At 18 V And 25°C, 5-V, 10-V, And 15-V Parametric Ratings
- The CD14538B Dual Precision Monostable Multivibrator Provides Stable Retriggerable/resettable One-Shot Operation For Any Fixed-Voltage Timing Application.
- Schmitt-Trigger Input Allows Unlimited Rise And Fall Times On +TR And -TR Inputs, 100% Tested For Maximum Quiescent Current At 20 V, Noise Margin (full Package-Temperature Range): 1 V At VDD = 5 V, 2 V At VDD = 10 V, 2.5 V At VDD = 15 V, Meets All Requirements Of JEDEC Tentative Standard No. 13B, "Standard Specifications For Description Of 'B' Series CMOS Devices"
